HAWKE CABLE GLAND

Specifications:
Reference :  421

Thread : M16 –  M100 / ½”NPT – 4”NPT

Cable sizes (OD): 3,2 – 91.6mm
Material (standard): Brass

Protection:
Ex II 2GD Ex db IIC Gb;
Ex eb IIC Gb; Extb IIIC Db
IP66 / IP67 / IP68
-60°C to +100°C

Available in:
Nickel-plated brass
Stainless steel

See documentation (PDF)

See Instructions (PDF)

for Lead sheath cable glandSpecifications:

Reference :  453R/L

Thread : M20 –  M100 / ½”NPT – 4”NPT

Cable sizes (OD): 9.5 – 104.5mm
Material (standard): Brass

Protection:
Ex II 2GD Ex db IIC Gb; Ex eb IIC Gb;
Ex nR IIC Gc; Extb IIIC Db
IP66 / IP67 / IP68
-60°C to +80°C

Available in:
Nickel-plated brass
Stainless steel

See documentation (PDF)

See Instructions (PDF)

Specifications:
Reference :  453U

Thread : M20 –  M100 / ½”NPT – 4”NPT

Cable sizes (OD): 5.5 – 104.5mm
Material (standard): Brass

Protection:
Ex II 2GD Ex db IIC Gb; Ex eb IIC Gb;
Ex nR IIC Gc; Extb IIIC Db
IP66 / IP67 / IP68
-60°C to +80°C

Available in:
Nickel-plated brass
Stainless steel

See documentation (PDF)

See Instructions (PDF)

for armoured and non-armoured cable compound barrier cable gland

Specifications:
Reference :  653U

Thread : M20 –  M75 / ½”NPT – 3”NPT

Cable sizes (OD): 5.5 – 78.0mm
Material (standard): Brass

Protection:
Ex II 2GD Ex db IIC Gb; Ex eb IIC Gb;
Ex nR IIC Gc; Extb IIIC Db
IP66 / IP67 / IP68
-60°C to +80°C

Available in:
Nickel-plated brass
Stainless steel

See documentation (PDF)

See Instructions (PDF)
